Mercury 3000U Elite Smart UPS:
Capacity |
|
|---|---|
| VA/Watts | 3000VA/1800W |
Input |
|
| Nominal Voltage | 220VAC / 240VAC |
| Voltage Range | 140VAC-300VAC |
| Frequency | 50/60Hz |
Output |
|
| Output Voltage | 220VAC / 240VAC |
| Voltage Regulation | Battery mode: ±10% |
| Waveform | Modified sinewave |
| Rear Output Socket | Battery backup: 4 x Universal |
Battery |
|
| Battery Type | 12V/9AH x 4 |
| Charging Time | 6-8 hours to recover to 90% capacity |
| Charge Current | Normal mode: About 1A |
| Charging Voltage | 54.8VDC |
System Features |
|
| Transfer Time | 10ms |
| Audible Alarm | Battery mode: Sounding every 10 sec / Battery low: Sounding every 1 sec / Overload: Sounding every 0.5 sec / Fault: Continuous sounding |
LED Indications |
|
| AC Mode | UPS in AVR mode, this LCD symbol flashes |
| Battery Mode | When AC input voltage is abnormal, this LCD symbol lights |
| Fault | This LCD symbol lights when UPS in fault mode, such as output shorted, over charge, over load |
Protection |
|
| Short Circuit Protection (Line Mode) | Fuse and firmware protection |
| Short Circuit Protection (Battery Mode) | Software protection controlled by firmware |
| Overload Protection (Line Mode) | Load>110%+20%/-10% after 5 minutes and go to fault, Load>120%+20%/-10% shut down immediately and go to fault. |
| Overload Protection (Battery Mode) | Load>110%±5% shut down after 5 secs Load>120%±5% shut down immediately. |
Environmental |
|
| Humidity | 0-90% Relative Humidity 0-40˚C (Non-condensing) |
| Noise Level | Less than <40dB |
Physical |
|
| Dimension W x D x H (mm) | 436 x 145 x 211.7, Master carton: 525 x 225 x 320 (1pcs) |
| Net Weight (kgs) | 22.9±0.3 |
